NO |
Part Name |
Material |
|
1 |
Body |
WCB/CF8M/CF8 |
|
2 |
Ball |
SS316/SS304 |
|
3 |
Bonnet |
WCB/CF8M/CF8 |
|
4 |
Valve Cover Gasket |
SS304 |
|
5 |
Seat |
PTFE |
|
6 |
Seat |
SS304/SS316 |
|
7 |
Thrust Washer |
PTFE |
|
8 |
Stem Packing |
PTFE |
|
9 |
Junk Ring |
SS304 |
|
10 |
Handle |
SS304 |
|
11 |
Spring Wash |
SS304 |
|
12 |
Handle Nut |
SS304 |
|
13 |
Handle Lock |
SS304 |
|
DN |
L |
D |
H |
E |
|
6 |
54 |
12 |
49 |
100 |
|
10 |
54 |
12 |
49 |
100 |
|
15 |
58 |
15 |
53 |
105 |
|
20 |
69 |
20 |
58 |
118 |
|
25 |
79 |
25 |
73 |
128 |
|
32 |
97 |
32 |
77 |
137 |
|
40 |
102 |
38 |
86 |
169 |
|
50 |
116 |
48 |
96 |
169 |
|
65 |
159 |
64 |
113 |
215 |
|
80 |
171 |
78 |
145 |
237 |
