1PC Stainless Steel Flanged Ball Valve works by rotating the ball to control the passage of fluid. When the ball is rotated to a position perpendicular to the fluid passage, the valve closes, blocking the flow of fluid; when the ball is rotated to a position parallel to the fluid passage, the valve opens, allowing the passage of fluid.
Main Features
● Excellent material: made of stainless steel, with excellent corrosion resistance and high temperature resistance, suitable for a variety of media.
● Reliable sealing: the ball and the valve seat are precision fitted, and the sealing surface material is widely used such as plastic to ensure the sealing performance.
● Easy to operate: the switch is light, from fully open to fully closed only need to rotate 90 °, easy to control from a distance.
● Small fluid resistance: when the valve is in the open state, the fluid channel is unobstructed and the resistance coefficient is small.
● Wide range of application: a wide range of diameters, from a few millimetres to several metres can be applied, suitable for high vacuum to high pressure environment.
Technical Parameters
● Connection form: flange connection
● Material: stainless steel (such as SS304, SS316, etc.)
● Working pressure: according to specific models and specifications, such as PN16, etc.
● Applicable temperature: usually between -40°C and 210°C, depending on the material and sealing materials
● Applicable medium: water, oil, gas and other fluids
